Drip Irrigation Tape Recycling Washing & Pelletizing Production Line
Complete Recycling Solution from Waste Drip Irrigation Tape to Recycled PE Pellets
Waste drip irrigation tape can vary significantly depending on where it comes from. Clean production waste and used agricultural drip tape have very different recycling requirements. Therefore, the correct recycling process should be selected according to the actual material condition.
The HUAYA recycling line integrates the main recycling processes into one complete system:
Waste Drip Tape → Crushing → Washing → Dewatering & Drying → Extrusion & Filtration → Pelletizing → Recycled PE Pellets
The washing section can be configured with floating washing, friction washing, rinsing and mechanical dewatering. For materials with a higher level of contamination, additional washing processes can be selected. After cleaning and dewatering, the material enters the extrusion system for plasticizing, degassing and melt filtration before being processed into recycled pellets.
The complete line adopts a modular design concept, allowing customers to select the appropriate recycling process according to their actual waste material rather than investing in unnecessary equipment.
Three Recycling Solutions
Clean Production Scrap
Crushing → Extrusion → Filtration → Pelletizing
Suitable for relatively clean waste and scraps generated during drip tape production.
Used Agricultural Drip Tape
Crushing → Washing → Dewatering → Extrusion → Filtration → Pelletizing
Suitable for used drip irrigation tape collected from farms containing soil, sand and other common contaminants.
Heavily Contaminated Drip Tape
Crushing → Multi-stage Washing → Dewatering & Drying → Extrusion → Filtration → Pelletizing
Suitable for agricultural drip tape requiring a more intensive cleaning process. Hot washing and additional drying can be configured according to the actual material condition.
Key Features｜
- Designed for Drip Irrigation Waste — Focused on recycling waste drip tape, drip pipe and production scraps.
- From Waste to Recycled PE Pellets — Complete process from size reduction and cleaning to final pelletizing.
- Flexible Washing Configuration — Washing intensity can be selected according to the contamination level of the material.
- Multi-stage Cleaning — Floating washing, friction washing and rinsing can be combined for agricultural waste.
- Efficient Dewatering — Mechanical dewatering prepares washed material for subsequent extrusion.
- Extrusion, Degassing & Filtration — Supports stable processing of cleaned recycled material.
- Modular Configuration — Avoid unnecessary equipment investment for relatively clean production waste.
- Customized Recycling Solution — Configuration can be designed according to material condition, required capacity and final pellet application.
Suitable Raw Materials｜
Waste Drip Irrigation Tape · Drip Tape Production Scrap · Waste Drip Irrigation Pipe · Applicable PE Irrigation Waste
Final Product｜Recycled PE Pellets
The recycled pellets can be used as recycled PE raw material for further plastic processing. The actual application and addition ratio depend on the original material composition, contamination level, recycling process and quality requirements of the final product.
5.0
design customization
Please fill out the form below to request a quote or to request more information about us. Please be sure to upload customized requirement documents or pictures, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Please fill out the form below to request a quote or to request more information about us. please be as detailed as possible in your message, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
DRIP IRRIGATION TAPE RECYCLING PRODUCTION LINE
——Turn Waste Drip Tape into Recycled PE Pellets
HUAYA Drip Irrigation Tape Recycling Washing & Pelletizing Production Line provides a complete recycling solution for waste drip irrigation tape, drip irrigation pipe, production scraps and other applicable PE irrigation waste.
The complete line can be customized with crushing, washing, dewatering, drying, extrusion, filtration and pelletizing systems according to the condition of the customer's waste material and required final product.
From waste drip tape to recycled PE pellets, HUAYA provides a complete recycling solution according to your raw material condition, required capacity and final application.
Why Choose
HUAYA Drip Tape Recycling Line?
01 — Complete Recycling Solution
From crushing and washing to dewatering, extrusion and pelletizing, the complete line can be configured according to the customer's waste material condition.
02 — Designed for Drip Irrigation Waste
Suitable for recycling waste drip irrigation tape, drip irrigation pipe and production scraps.
03 — Multi-stage Washing System
Pre-washing, floating washing, friction washing and rinsing can be configured to clean agricultural drip tape waste before pelletizing.
04 — Optional Hot Washing
For heavily contaminated waste materials, an additional hot washing system can be configured according to the actual recycling requirement.
05 — Efficient Dewatering
Mechanical dewatering reduces surface moisture of washed materials before the extrusion and pelletizing process.
06 — Stable Extrusion & Filtration
Degassing and melt filtration systems can be configured to support stable recycled pellet production.
07 — Customized Configuration
The production line is customized according to material condition, contamination level, required capacity and final pellet application.
Low-speed, high-torque shredding with hydraulic feeding and automatic overload reverse protection provides reliable size reduction for waste plastic materials.
· Motor Power: 22 kW
· Effective Cutter Shaft Length: 600 mm
· Cutter Quantity: 34 pcs
· Cutter Material: D2
· Shaft Speed: 80 rpm
· Screen Aperture: Φ50 mm
2、Washing System
Multi-stage Floating Washing & Separation
Multiple washing and separation stages help remove sand, soil and other contaminants from crushed drip tape materials before extrusion.
· Tank Length: 5000 mm
· Width: 1000 mm
· Height: 1000 mm
· Motor Power: 3 kW
3、Friction Washing System
High-Efficiency Friction Washing——Further cleans the crushed material after pre-washing and helps remove residual surface dirt and impurities before rinsing and dewatering.
· Length: 3000 mm
· Diameter: 400 mm
· Motor: 7.5 kW
· Blade Thickness: 6 mm
4、Dewatering System
Mechanical Dewatering——High-speed mechanical dewatering reduces surface moisture after washing and prepares the material for subsequent drying or pelletizing.
· Length: 2500 mm
· Width: 750 mm
· Motor Power: 15 kW
· Screen: 304 Stainless Steel
5、Extrusion & Pelletizing System
Extruder Type | Customized |
Screw Diameter | According to capacity |
Screw Design | Customized for recycling material |
Degassing | Available |
Melt Filtration | Hydraulic screen changing available |
Pelletizing Method | According to configuration |
Capacity | Customized |
Technical Parameters
|
Item |
Specification |
|
Product |
Drip Irrigation Tape Recycling Washing & Pelletizing Line |
|
Raw Material |
Waste drip irrigation tape / drip pipe / production scraps |
|
Main Process |
Crushing → Washing → Dewatering/Drying → Pelletizing |
|
Crushing System |
Shredder / Crusher, customized according to material |
|
Washing Method |
Pre-washing / Floating washing / Friction washing / Rinsing |
|
Hot Washing |
Optional |
|
Dewatering |
Mechanical dewatering |
|
Drying System |
Optional / according to material condition |
|
Extrusion |
Customized according to recycling material |
|
Degassing |
Available |
|
Filtration |
Hydraulic screen changing available |
|
Pelletizing |
Customized |
|
Final Product |
Recycled PE pellets |
|
Capacity |
Customized according to raw material and configuration |
|
Electrical System |
PLC / centralized electrical control according to configuration |
|
Voltage |
Customized according to customer's local power supply |
|
Line Layout |
Customized according to customer's factory |
Customer Case
In 2025, HWYAA partnered with a top Uzbek water-saving irrigation enterprise. Plagued by inefficiencies of traditional manual punching, the enterprise inspected HWYAA's pre-drilling line in China, confirmed satisfaction on-site, and signed the contract immediately.
HWYAA delivered the equipment as scheduled, with on-site installation, commissioning and full training provided by our engineers. The client praised: "Stable operation, easy operation, exceeding expectations" — its productivity and competitiveness improved significantly.
Driven by proven benefits and trust, the client plans to purchase all available stock.
Machine testing
Leading water-saving irrigation enterprise from uzbekistan visits china for factory inspection and machine testing
Customized Solution
Plc precision hole control + ultrasonic integrated forming + touchscreen easy operation
Machine Testing
Engineers dispatched for on-site installation and training
Fastest Repurchase
Recognized immediately after first order delivery, client says "take all available stock"
In-stock Packing
Fast Shipping
F A Q
Q1. Can this line recycle used drip irrigation tape collected from farms?
Yes. The line can be configured with crushing, washing, dewatering and pelletizing systems according to the condition and contamination level of the collected material.
Q2. Do I need a washing line for clean production scraps?
Not necessarily. The configuration depends on the cleanliness and condition of the waste material. Please send us photos or videos of your material for evaluation.
Q3. Is hot washing necessary?
Hot washing is an optional process. The appropriate washing process should be selected according to the contamination condition of the waste material.
Q4. What capacity can you provide?
The required capacity should be determined together with the raw material condition and complete line configuration.
Q5. Can recycled pellets be used again for drip irrigation tape production?
The application and addition ratio of recycled pellets depend on the material composition, contamination level, recycling process and required quality of the final drip irrigation product. We recommend evaluating the recycled material before determining the formulation.
